INDUSTRY CASTING SOLUTIONS
Custom housings, machine structures, rotating components and general machinery castings developed from your drawing, sample or equipment reference.
Industrial equipment + housings, bases, brackets and rotating cast components
01 / FEATURED CAST COMPONENTS
Product cards connect the industry use case to an existing product route or a focused RFQ discussion.
02 / PRODUCT CATEGORIES
Product categories organize the search around the function and equipment interface instead of a random list of products.
Cast enclosures and support interfaces around drive and rotating systems.
Bases, frames and supports developed around rigidity, damping and assembly references.
03 / TYPICAL APPLICATIONS
Use the equipment or system closest to your project to find a focused starting point.
Housings and supports for drive assemblies where alignment, machining and vibration behavior matter.
Cast components for motor, shaft and support systems with defined assembly interfaces.
Bases, frames and brackets shaped around rigidity, damping and the machine layout.
Drawing-based castings for custom equipment and replacement components.
04 / MATERIALS FOR THIS INDUSTRY
Material families shown here are starting points. Exact grades, treatment and documentation are confirmed against the customer specification.
A useful discussion option for machine bases and housings where machinability, damping and dimensional stability are important.
Typical applicationsMachine bases · Motor housings · CoversA balanced material option for structural housings, hubs and supports requiring strength and practical machining.
Typical applicationsGearbox housings · Bearing housings · HubsSelected for structurally demanding components after loading, geometry and inspection requirements are reviewed.
Typical applicationsFrames · Supports · Heavy housingsConsidered for selected rotating, wear-facing and custom structural castings where strength or heat treatment matters.
Typical applicationsPulleys · Flywheels · Custom castings05 / RECOMMENDED CASTING PROCESSES
Only processes relevant to this industry are shown. Final selection depends on geometry, material, quantity and required quality.
Large housings, bases and machine structures
Selected smaller housings and detailed castings
Small complex brackets and rotating components
Integrated or complex housing geometry
06 / CUSTOM CASTING CAPABILITIES
Send the information already available. The team can then confirm the manufacturing route, missing inputs and the useful basis for quotation.
Review drawing revisions, critical dimensions and the information needed for a manufacturable route.
Use available 3D data to discuss geometry, tooling and machining references.
Start with a sample, photo or equipment reference when a drawing is not yet available.
Confirm material, hardness and application requirements before quotation.
Match product references, fitment and customer identification requirements.
Align tooling, sample review and repeat production around the confirmed project scope.
07 / MACHINING & SECONDARY OPERATIONS
Secondary operations are reviewed according to the drawing, application and agreed delivery condition.
Process and material selection starts from the component geometry and application.
→Application-matched heat treatment is discussed where the confirmed material and part require it.
→Machining requirements, datum references and fit-critical dimensions are reviewed with the drawing.
→Cleaning, shot blasting and other finishing requirements are confirmed per part.
→The inspection plan is aligned with material, geometry, application and customer requirements.
→Identification and packing are agreed around part protection, labeling and shipment requirements.
08 / QUALITY & INSPECTION
Inspection methods and records are selected according to the confirmed customer specification. The listed checks are discussion points, not blanket claims for every part.
Material grade and required documentation are checked against the agreed specification.
Hardness requirements are confirmed for parts where wear or fit performance depends on them.
Critical dimensions, interfaces and machining references are checked against the drawing.
Surface condition, casting appearance and finishing requirements are reviewed before packing.
09 / HOW WE MANUFACTURE YOUR CASTINGS
Melting, molding, pouring, finishing, machining and inspection are connected into a project-specific route.
11 / FAQ
Housings, bases, frames, brackets, hubs, pulleys, flywheels, covers and other drawing-based machinery components can be reviewed.
Share the machine layout, drawing or existing sample so the size, material, casting route, machining references and handling requirements can be assessed.
Machining can be included when the drawing provides the datums, tolerances and fit-critical surfaces needed for a clear manufacturing plan.
Green sand casting is a practical starting point for many housings; shell moulding, lost foam or another route can be discussed based on geometry and volume.
Low-volume work can be reviewed from a drawing, model or sample, with tooling and approval requirements confirmed for the project.
Yes. A physical sample, photos and equipment reference can start the review when complete drawings are not available.
REQUEST A QUOTE
Send us your drawing, material requirement, quantity and application. Our team will review the project and recommend a suitable manufacturing route.
